RFCI公司800MHz至16000MHz法兰安装式插入式环形器
发布时间：2025-10-11 08:59:26 浏览：541
RFCI公司800MHz至16000MHz法兰安装式插入式环形器
型号参数
| Part Number | Frequency Range | Insertion Loss | Isolation | Return Loss | Forward Power p | Rev Power | Operating Temperature | Package Outline |
| (dB) | (dB) | (dB) | CW (W) | CW (W) |
| Low | High | Room/OT | Room/OT | Room/OT | Max. | Max. | (°C) | Figure |
| RFCR8411 | 800 | 1400 | 0.50/0.60 | 16/15 | 16/15 | 500/50 | 50 | -0 to +50°C | BDC-01 |
| RFCR8410 | 900 | 1500 | 0.40/0.60 | 20/19 | 20/19 | 500/50 | 50 | -0 to +50°C | BDC-01 |
| RFCR8401 | 1000 | 2000 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 50 | -0 to +50°C | BDC-01 |
| RFCR8501 | 1250 | 2500 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 50 | -0 to +50°C | BDC-01 |
| RFCR8502 | 1300 | 2600 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 50 | -0 to +50°C | BDC-01 |
| RFCR8503 | 1350 | 2700 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 50 | -0 to +50°C | BDC-01 |
| RFCR8703 | 1500 | 3000 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 30 | -10 to +65°C | BDC-02 |
| RFCR8704 | 1600 | 3200 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 30 | -10 to +65°C | BDC-02 |
| RFCR8801 | 2000 | 4000 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 30 | -10 to +65°C | BDC-02 |
| RFCR8810 | 2000 | 3000 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 30 | -10 to +65°C | BDC-02 |
| RFCR8805 | 2100 | 4200 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 30 | -10 to +65°C | BDC-02 |
| RFCR8806 | 2500 | 5000 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 30 | -10 to +65°C | BDC-02 |
| RFCR8807 | 2600 | 5200 | 0.50/0.70 | 19/17 | 19/17 | 500/50 | 30 | -10 to +65°C | BDC-02 |
| RFCR8902 | 3000 | 6000 | 0.50/0.70 | 19/18 | 19/18 | 500/50 | 30 | -20 to +85°C | BDC-03 |
| RFCR8912 | 3200 | 6400 | 0.50/0.60 | 19/18 | 19/18 | 500/50 | 30 | -20 to +85°C | BDC-03 |
| RFCR8907 | 3500 | 7000 | 0.50/0.60 | 19/18 | 19/18 | 500/50 | 30 | -20 to +85°C | BDC-03 |
| RFCR8915 | 4000 | 8000 | 0.50/0.60 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8918 | 4500 | 9000 | 0.50/0.60 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8920 | 5000 | 10000 | 0.50/0.60 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8921 | 5200 | 10400 | 0.50/0.60 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8923 | 5500 | 11000 | 0.50/0.60 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8924 | 6000 | 12000 | 0.50/0.60 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8925 | 6500 | 13000 | 0.50/0.60 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8928 | 7000 | 14000 | 0.50/0.70 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8927 | 7000 | 12400 | 0.50/0.60 | 20/19 | 20/19 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8930 | 7500 | 15000 | 0.60/0.70 | 19/17 | 19/17 | 250/30 | 20 | -40 to +85°C | BDC-04 |
| RFCR8932 | 8000 | 16000 | 0.60/0.70 | 19/17 | 19/17 | 250/30 | 10 | -40 to +85°C | BDC-05 |
| RFCR8933 | 8000 | 12400 | 0.50/0.60 | 21/20 | 21/20 | 250/30 | 10 | -40 to +85°C | BDC-05 |
| RFCR8936 | 9000 | 18000 | 0.60/0.70 | 19/17 | 19/17 | 250/30 | 10 | -40 to +85°C | BDC-05 |
| RFCR8937 | 10000 | 20000 | 0.70/0.90 | 16/15 | 16/15 | 250/30 | 10 | -40 to +85°C | BDC-05 |
| RFCR8938 | 10000 | 15000 | 0.50/0.60 | 21/19 | 21/19 | 250/30 | 10 | -40 to +85°C | BDC-05 |
| RFCR8939 | 11000 | 18000 | 0.60/0.70 | 19/17 | 19/17 | 250/30 | 10 | -40 to +85°C | BDC-05 |
产品特点
频率范围：800MHz至16000MHz，覆盖宽频段。
性能优势：低插入损耗、高隔离度，保证信号传输质量。
封装尺寸：提供标准和微型封装，适应不同空间需求。
工作温度：适应宽温度范围，适合多种环境。
功率处理：高功率处理能力，适用于高功率系统。
结构设计：坚固耐用，符合RoHS标准，环保且可靠。
磁屏蔽：有效防止磁场干扰，提高电磁兼容性。
应用场景
宽带通信：适用于宽带无线接入、卫星通信等。
功率放大器：保护放大器，提高系统稳定性和可靠性。
定制化服务
旋转方向：顺时针或逆时针旋转可选。
引脚偏移：提供特殊引脚偏移设计。
定制设计：满足特殊频率、尺寸、功率等需求。
测试夹具：提供测试夹具和S参数，便于测试和评估。
RFCI是一家专业生产射频(RF)环行器和隔离器的公司，产品覆盖了从50 MHz到20 GHz的频率范围，广泛应用于通信和无线基础设施。深圳市新葡萄AMG创展科技有限公司优势代理销售RFCI产品，欢迎咨询了解。
