JQL Technologies大功率UHF同轴隔离器

发布时间：2025-10-20 13:52:06 浏览：499

Part Number	Band (GHz)	Bandwidth (GHz)	Isolation	Ins Loss	VSWR	Avg Power
JIC0390T0450SFSF10	0.390~0.450	Full	18	0.5		-/-/100
JI2C0150T0174MS1	0.150~0.174	Full	40	0.8	1.25	100/10
JIC0313T0317N5	0.313~0.317	Full	25	0.25	1.15	100/10
JIC0698T0960S1	0.698~0.960	Full	20	0.4	1.25	100/10
JIC0700T1000S10	0.700~1.000	Full	18	0.5	1.3	100/10
JI2C0700T0800S1	0.700~0.800	Full	40	0.5	1.15	100/10
JIC0150T0158N10R	0.150~0.158	Full	20	0.5	1.25	100/100
JI2C0450T0470N10	0.450~0.470	Full	50	0.5	1.22	100/100
JIC0512T0698N10	0.512~0.698	Full	18	0.4	1.28	100/100
JIC0800T0960S10	0.800~0.960	Full	20	0.4	1.22	100/100
JIC0820T0915BNC10	0.820~0.915	Full	22	0.3	1.22	100/100
JIC0855T0895S10	0.855~0.895	Full	21	0.25	1.19	100/100
JIC0925T0960S10	0.925~0.960	Full	22	0.25	1.15	100/100
JIC0960T1240S10	0.960~1.240	Full	20	0.3	1.22	100/100
JIC0415T0455SF10	0.415~0.455	Full	25	0.4		100/100/-
JI2C0450T0470N10-Ver2	0.450~0.470	Full	50	0.7		100/100/-
JIC0770T0960SMSF10	0.700~0.960	Full	18	0.5		100/100/-
JIC0280T0330N10	0.280~0.330	Full	20	0.5		100/100/200
JIC0902T0928S2	0.902~0.928	Full	20	0.5	1.22	100/20
JIC0465T0468N2	0.465~0.468	Full	25	0.25	1.15	100/25
JIC0119N3	0.119~0.120	Full	19	0.5	1.25	100/30
JIC0123N3	0.123~0.124	Full	19	0.5	1.25	100/30
JIC0134N3	0.133~0.135	Full	19	0.5	1.25	100/30
JIC0150T0180N3R	0.150~0.180	Full	19	0.5	1.25	100/30
JIC0380T0430N5	0.380~0.430	Full	20	0.3	1.22	100/50
JIC0431T0435N5	0.431~0.435	Full	25	0.25	1.15	100/50
JIC0118T0144NF2	0.118~0.144	Full	17	1	0	100/50/100
JIC0400T0465N6	0.400~0.465	Full	25	0.25	1.2	100/60
JIC0465T0530N6	0.465~0.530	Full	25	0.25	1.2	100/60
JIC0145T0165N3R	0.145~0.165	Full	22	0.6	0	125/-/-
JIC0763T0776N1	0.763~0.776	Full	19	0.25	1.25	125/10
JIC0860T0960S1	0.860~0.960	Full	20	0.3	1.22	125/10
JIC0430T0470N6	0.430~0.470	Full	25	0.3	1.15	125/100
JIC0350T0385N6	0.350~0.385	Full	25	0.3	1.22	125/60
JIC0380T0415N6	0.380~0.415	Full	25	0.3	1.15	125/60
JIC0405T0440N6	0.405~0.400	Full	25	0.3	1.15	125/60
JIC0459T0512N6	0.459~0.512	Full	25	0.3	1.15	125/60
JIC0135T0155N10R	0.135~0.155	Full	20	0.5	1.25	150/100
JIC0144T0149N10R	0.144~0.149	Full	20	0.5	1.25	150/100
JIC0149T0151S10R	0.149~0.151	Full	20	0.4	1.22	150/100
JIC0155T0175S10	0.155~0.175	Full	20	0.5	1.25	150/100
JI2C0800T0960S10	0.800~0.960	Full	40	0.8	1.25	150/100
JI2C0860T0872S10	0.860~0.872	Full	50	0.5	1.15	150/100
JI2C0156T0162N10	0.156~0.162	Full	50	0.8		150/100/-
JIC0132T0144N15R	0.132~0.144	Full	19	0.5	1.25	150/150
JIC0315T0433N5	0.315~0.433	Full	20	0.5	1.25	150/50
JIC0249T0251N6R	0.249~0.251	Full	21	0.3	1.2	150/60
JIC0851T0869N6	0.851~0.869	Full	25	0.3	1.15	150/60
JIC0450T0520N10	0.450~0.520	Full	20	0.5	1.25	150/75
JIC0380T0440N2	0.390~0.450	Full	20	0.4		20/20/100
JIC0300T0420S10	0.300~0.420	Full	18	0.5	1.3	200/100
JIC0300T0420N10	0.300~0.420	Full	18	0.5	1.3	200/100
JIC0420T0450N10	0.420~0.450	Full	25	0.25	1.25	200/100
JIC0470T0512N15	0.470~0.512	Full	25	0.25	1.2	200/100
JI2C0390T0410NFNM10	0.390~0.410	Full	48	0.5	1.19	250/100
JI2C0410T0430NFNM10	0.410~0.430	Full	50	0.5	1.2	250/100
JI2C0406T0430N3	0.406~0.430	Full	50	0.5	1.2	250/30
JIC0350T0400S10	0.350~0.400	Full	20	0.4	1.25	250/50
JIC0350T0500N10	0.350~0.500	Full	16	0.7	1.4	300/100
JI2C0900T0960N30	0.900~0.960	Full	60	0.5	1.2	300/100
JIC0390T0450N15	0.390~0.450	Full	20	0.4	1.25	300/150

　JQL Technologies是一家领先的射频和微波设备制造商，公司主要设计和生产高性能射频/微波组件，包括滤波器、隔离器与环行器、定向耦合器、功率分配器/合路器、混合器、终端等。深圳市新葡萄AMG创展科技有限公司，优势代理销售JQL产品，欢迎咨询。
